1863 Schematics of Alligator by de Villeroi

Although dated 1863, these schematics show the Alligator as originally designed by Brutus de Villeroi, (e.g., note the paddle propulsion system, which was replaced by a central screw propeller in the vessel's winter 1862/63 refit).
